Commercial Potato cutting Machine

Type: cutter
Condition: new
Material: stainless steel
Capacity: 1000kg/h
Cutting size: 5mm, 8mm, 10mm.etc
Availability:
Quantity:

Application:

    This commercial potato slicer machine is suitable for slicing potato carrot .etc hard vegetables. It is an ideal processing equipment for producing fresh vegetables and dehydrated vegetables in the vegetable processing industry. It is also an ideal machine for fast food processing and fries.


Structural Characteristics

    The main frame, shell, dial tray, cutter, transmission part, the material cover and other components.

Commercial Potato cutting Machine

Working Principle

    When working, the potato material is put into the hopper, the material is guided along the shell wall by the reverse feed hopper on the rotating dial tray, the cutter mounted on the shell wall cuts the vegetables into strips and slice, Material cover out.


Products Specifications:

Commercial Potato cutting Machine
Commercial Potato cutting Machine

Commercial Potato cutting Machine


commercial potato slicer machine
commercial potato slicer machine
commercial potato slicer machine


Machine Picture


commercial potato slicer machine
commercial potato slicer machine
commercial potato slicer machine


Notes

Using machine correctly is the key to play its performance, therefore, the following items should be noticed:

>>Slicing blade should be attached barrel closely, blade edge and barrel are supposed to be vertically tightened.

>>Slivers blade is put in the knife case and keep the tip be lined up.

>>Slivers blade is fixed to the barrel,the blade tip should be higher by 0.5-1mm.

>>After fixing the blades,please adjust the active boards,please make the same clearance between two boards.

>>When slicing,discharge the slivers cutter.Adjust the slicing blade position to make the blade edge and adjustable board edge in the same line.

>>Before using,please ensure the slicing blade,slivers blade and active board are tighten fixed.
